| Number of Tracks | Simultaneous Recording Tracks: 2 (stereo mode), 4 (4-channel mode), 2 (MTR mode) Simultaneous Playback Tracks: 2 (stereo mode), 4 (4-channel mode), 4 (MTR mode) |
| Recording Time | 4 GB with SDHC: Approx. 380 minutes (WAV 44.1 kHz/16-bit stereo track) Approx. 68 hours (MP3 44.1 kHz/128 kbps stereo track) * Recording times are approximations |
| Recording File Size | Maximum: 2 GB |
| Project Files | 1000/card |
| Locate Function | Hours/Minutes/Seconds/Milliseconds |
| Other Functions | Punch-in/out, Bounce, A-B repeat |
| Effects | Modules: 2 Stereo/4 Ch Mode: Lo Cut, Compressor/Limiter MTR Mode: Pre Amp module, EFX module |
| Type | 53 |
| Patches | 60 |
| Tuners | Chromatic, Guitar, Bass, Open A/D/E/G, DADGAD |
| Metronome | Sound Sources: 5 |
| Beat | Variable: 1/4 to 8/4, 6/8, unaccentuated |
| Tempo | 40.0 to 250.0 BPM |
| A/D and D/A Conversion | 24-bit x 128 oversampling |
| Recording Media | SD card (16 MB to 2 GB), SDHC card (4 to 32 GB) |
| Display | 128 x 64 dots full-dot backlit LCD |
| Data Type | WAV Format (Record/Play) Quantization: 16/24-bit Sampling Frequency: 44.1, 48, and 96 kHz MP3 Format (Recording) Bit Rate: 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320kbps, VBR Sampling Frequency: 44.1 kHz MP3 Format (Playback) Bit Rate: 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320kbps, VBR Sampling Frequency: 44.1/48 kHz |
| Inputs | |
|---|---|
| General | 1 & 2: XLR (balanced input) / 1/4" (6.3 mm) phone (unbalanced input) combo jack |
| Input Impedance | Balanced: 3 kOhms or more, pin-2 hot Unbalanced: 470 kOhms or more |
| Input Gain | Balanced: -16 to 43 dB Unbalanced: -30 to 32 dB |
| Built-In Microphone | Type: Unidirectional condenser microphone Sensitivity: -45 dB/1 Pa at 1 kHz Input gain: -16 to 51 dB Maximum SPL: 140 dB |
| External Microphones | Connection: 3.5mm Mini stereo phone jack Input impedance: 2 kOhms or more Input gain: - 16 to 51 dB |
| Outputs | |
|---|---|
| Line / Phone | Line output load impedance: 10 kOhms or more Rated output level: -10 dBu Phone: 20 + 20 mW (into 32-Ohms load) |
| Speaker | 400 mW 8 Ohms |
| Phantom Power | 48 & 24 V, Off |
| USB | USB 2.0 High-Speed mass-storage class operation, audio interface operation (USB functions can be operated by USB bus power) |
| Power Requirements | 5 VDC from AC adapter (ZOOM AD-14) |
| Batteries | 2 x IEC R6 (size AA) - (Battery not included) |
| Continuous Recording Time | Stereo mode: (With built-in mics at 44.1 kHz/16-bit without headphones connected): 6 hours with alkaline batteries, 8 hours with NiMH batteries. Stamina mode: (With built-in mics at 44.1 kHz/16-bit without headphones connected): 10 hours with alkaline batteries, 12 hours with NiMH batteries. |
| Dimensions (W x D x H) | 2.9 x 6.6 x 1.5" / 73 x 167.2 x 37 mm |
| Weight |
10 oz / 294 g |
